Tile - Tile

The availability of features depends on the license and may not be available in all deployments.

Single component value Tile group - TileGroup, single-choice field (the field can only be placed inside a tile group).

Component properties

Eximee Designer property	Attribute name in Source	Description
Selected field value (section Basic properties)	option	Component value - the field cannot be empty
Content (section Basic properties)	content	Tile content (may be overridden by the service)
Title (section Basic properties)	title	Title displayed above the tile. Availability of this feature depends on the license and may not be available in all deployments.
Additional content (key) and Additional content (section Basic properties)	additionalContentKey	Translation key containing the tile's additional content, in a format analogous to Content. Functionally it may behave differently depending on the chosen deployment, for example content that should be additionally displayed when a given tile is selected (may be overridden by the service). Availability of this feature depends on the license and may not be available in all deployments.
Title color	titleColor	Title background color in hexadecimal format. Availability of this feature depends on the license and may not be available in all deployments.
Popup trigger label (key) and Popup trigger label	popupTriggerLabelKey	Label text which, when clicked, will show the popup. Availability of this feature depends on the license and may not be available in all deployments.
Additional content in the popup	popupTextContent	Name and version of the text content (in the format name-version) that will be shown in the popup. Availability of this feature depends on the license and may not be available in all deployments.

NOTE! Contextual help for Tile can be defined, but without using a help icon (the help tooltip may only appear on hover over the tile).

More information about component properties: Common component properties

Component input parameters

Parameter	Description
content	Tile content written in HTML or WikiMarkup (scripts inside this HTML are not supported by the platform).
additionalContent	Tile content written in HTML or WikiMarkup, overriding the value taken from the translation additionalContentKey described in the component properties.
markupType	Type of tile content - values supported are those such as for Content (Text Content). Optional parameter - the default value is HTML.
popupTriggerLabel	Label text which, when clicked, will show the popup. Availability of this feature depends on the license and may not be available in all deployments.
popupTextContent	Name and version of the text content (in the format name-version) that will be shown in the popup. Availability of this feature depends on the license and may not be available in all deployments.

Illustration 1. Example appearance of the component on the form

Demo form: demoTileGroup
